MTN Wheel Type Mobile Crushing And Screening Plant

Feeding Size：≤800mm
Capacity：70-650t/h

The MTN series rubber-tired mobile production line comprehensively covers processing demands ranging from 100 to 300 tons per hour in the fields of hard rock, soft rock, and construction waste treatment applications. The mobile plant features an aesthetically pleasing design, fine craftsmanship, and is equipped with main unit of the latest technology, which ensure stable and reliable performance and high output. Each mobile plant is equipped with crawler devices, ensuring rapid installation and commissioning upon arrival at the site, which reduce the foundation preparation time.

Consult online Send Inquiry

EQUIPMENT ADVANTAGE

Modular Design

odular and universal design allows devices with the same processing capability to achieve maximum versatility. The main unit can be switched to adjust different materials and realize quick production.

Humanized Maintenance Platform

The maintenance platform features a front-to-back connected design, inclined staircases and widened steps for increased safety and convenience. Some models are added a small rear ladder to facilitate easier inspection and maintenance.

Vehicle-mounted Belt Conveyor

Every machine the mobile production line is equipped with vehicle-mount belt conveyor, eliminating the need for disassembly during transport. Upon arrival at the site, we can organize our work quickly, neatly and orderly.

Eliminating Basic Installation

Each piece of equipment provides a support plate device, reducing the need for foundational investment. This design can be retracted during transportation and relocation, and quickly deployed upon arrival at the site.

Vehicle-mount Electronic Control System

Equipped with an independent electric control system for easy operation, all equipment cables already have been connected before leaving the factory. It is no need for disassembly during transport and allows for rapid on-site commissioning upon arrival.

Large Capacity Silo Design

The large-capacity silo allows for easy loading and can store a certain amount of material, ensuring uniform and stable feeding.

WHAT PEOPLE SAY?

The jaw crusher is a solid piece of equipment. It's built tough and handles even the hardest materials with ease. It’s easy to use and maintain, which is a big plus if you’re working on a busy site. The crusher gives you consistent, reliable performance, and the adjustable settings let you control the size of the crushed material to suit your needs.

Mike peter

USA

24/08/2023

I've been using the Recycling Construction Waste service, and it’s been a game-changer for my projects. The whole process is straightforward and efficient, making it easy to get rid of debris and leftover materials. I love that it’s eco-friendly—knowing that the waste is being repurposed rather than just ending up in a landfill is a big deal for me. Plus, it saves me money on disposal costs and helps keep my worksite clean and organized. Overall, it’s a reliable, cost-effective solution that I’d highly recommend to anyone in construction.

Matthew

Jamaica

12/04/2024

This cone-crushing production line exceeded my expectations. The finished products after processing are of good quality, and the cubic content of the products is more than 85%. After selling them, the profit is high. I am very grateful to FTM Machinery and will continue to expand the business in the future.

Nathan

Germany

06/11/2022

I am very satisfied with this rock crusher. Its crushing efficiency is truly impressive; it can process a large amount of stone in a short time, completely exceeding my expectations. The crushing effect is also excellent, producing uniformly sized stone particles of high quality, perfectly meeting the needs of our construction projects.

Patrick

The Philippines

08/10/2023

What surprises me even more is the durability of this crusher. I've been using it for a while now, and it has hardly had any issues. Maintenance is also very convenient, saving a lot of time and costs. The operation is especially simple, with an intuitive control system that even beginners can quickly master.

Ryan

Indonesia

17/01/2024

TECHNICAL PARAMETERS

Series	Standard Model	On board equipment	On board equipment	Processing Capability (t/h)	Transport dimensions (mm)
FOUR COMBINATION MOBILE STATION	MTN100Y-2	GZD850X3000/2YK1545	HD72/GYS300	50-100	15000x2650x4500
	MTN100Y-3	GZDT0835/3HX1548	HDX86/SC100F1	50-100	17500x2500x4000
	MTN150Y-3	GZDT0835/3HX1548	HDX86/SC160F1	70-150	17500x2500x4000
	MTN150R-3	GZDT0835/3HX1548	HDX86/CI1110	60-150	17500x2500x4000
MOBILE COARSE CRUSHING STATION	MTN96	GZDT9538	CJ96	70-200	13000x2950x4250
	MTN98	GZDT9538	HDX98	80-200	13000x2950x4250
	MTN106	GZDT1145A	CJ106	90-300	14000x3000x4400
	MTN110	GZDT1145A	HDX110	120-300	14000x3000x4400
	MTN1213C	GZDT9538	CI1213	80-200	13000x2950x4250
	MTN1316C	GZDT1145A	CI1316	100-300	14000x3000x4400
MOBILE MEDIUM AND FINE CRUSHING STATION	MTN300	-	HPM300C1	100-200	15500x2900x4200
	MTN400	-	HPM400C3	150-300	16500x3100x4300
	MTN250	-	SC250F1	90-200	16500x3100x4300
	MTN1213	-	CI1213	80-200	16000x2900x4300
	MTN1316	-	CI1316	100-300	16500x3100x4500
	MTN0926	-	HVI0926	85-200	16500x3100x4300
	MTN1040	-	HVI1040	120-300	16500x3100x4400
MOBILE SCREENING STATION	MTN1865-3	-	3HX1865	65-200	14500x2900x4000
MOBILE SCREENING STATION	MTN2165-3	-	3HX2165	85-300	15000x2900x4400
MOBILE STATION FOR MEDIUM AND FINE CRUSHING AND SCREENING	MTN300S-3SII	3HX1865	HPM300C1	100-200	15000x3000x4000
	MTN300S-3	3HX2165	HPM300C1	100-200	15000x3000x4000
	MTN400S-3	3HX2165	HPM400C3	150-300	15000x3000x4000
	MTNG400S-3SII	3HX1865	GYS400C1	100-200	15000x3000x4000
	MTNG400S-3	3HX2165	GYS400C1	100-200	15000x3000x4000
	MTN250S-3	3HX2165	SC250F1	90-200	15000x3000x4200
	MTN1213S-3	3HX1865	CI1213	80-200	15000x3000x4200
	MTN1316S-3	3HX2165	CI1316	100-300	15000x3000x4200
	MTN0926S-2	2HX1865	HVI0926	85-200	18000x3000x4200
	MTN1040S-2	2HX2165	HVI1040	120-300	18000x3000x4200
THREE COMBINATION MOBILE STATION	MTN1213-III	GZDT9538/3HX1865	CI1213	80-200	18200x2800x4350
	MTN1316-III	GZDT1145A/3HX2165	CI1316	100-300	18200x3000x4200
	MTN1410-III	GZDT9538/3HX1865	PCZ1410	80-200	18200x2800x4200
	MTN1612-III	GZDT1145A/3HX2165	PCZ1612	100-300	18200x3000x4200

Series	Standard Model	Processing Capability (t/h)	Transport dimensions (mm)
FOUR COMBINATION MOBILE STATION	MTN100Y-2	50-100	15000x2650x4500
	MTN100Y-3	50-100	17500x2500x4000
	MTN150Y-3	70-150	17500x2500x4000
	MTN150R-3	60-150	17500x2500x4000
MOBILE COARSE CRUSHING STATION	MTN96	70-200	13000x2950x4250
	MTN98	80-200	13000x2950x4250
	MTN106	90-300	14000x3000x4400
	MTN110	120-300	14000x3000x4400
	MTN1213C	80-200	13000x2950x4250
	MTN1316C	100-300	14000x3000x4400
MOBILE MEDIUM AND FINE CRUSHING STATION	MTN300	100-200	15500x2900x4200
	MTN400	150-300	16500x3100x4300
	MTN250	90-200	16500x3100x4300
	MTN1213	80-200	16000x2900x4300
	MTN1316	100-300	16500x3100x4500
	MTN0926	85-200	16500x3100x4300
	MTN1040	120-300	16500x3100x4400
MOBILE SCREENING STATION	MTN1865-3	65-200	14500x2900x4000
MOBILE SCREENING STATION	MTN2165-3	85-300	15000x2900x4400
MOBILE STATION FOR MEDIUM AND FINE CRUSHING AND SCREENING	MTN300S-3SII	100-200	15000x3000x4000
	MTN300S-3	100-200	15000x3000x4000
	MTN400S-3	150-300	15000x3000x4000
	MTNG400S-3SII	100-200	15000x3000x4000
	MTNG400S-3	100-200	15000x3000x4000
	MTN250S-3	90-200	15000x3000x4200
	MTN1213S-3	80-200	15000x3000x4200
	MTN1316S-3	100-300	15000x3000x4200
	MTN0926S-2	85-200	18000x3000x4200
	MTN1040S-2	120-300	18000x3000x4200
THREE COMBINATION MOBILE STATION	MTN1213-III	80-200	18200x2800x4350
	MTN1316-III	100-300	18200x3000x4200
	MTN1410-III	80-200	18200x2800x4200
	MTN1612-III	100-300	18200x3000x4200
